Product
| Basic Information | |
| Standard Serial ATA | SATA III, 6.0Gbps (Backward compatible with SATA 1.5 and 3.0Gbps) |
| Form Factor | mSATA (50.80mm x 29.85mm x 3.40mm) L×W×H |
| Connector | 52 pin |
| Capacities | 480GB~960GB (3D-TLC SSD) |
| Input Voltage | 3.3V (±5%) |
| Type | Industrial SSD |
| Performance | |
| Max Sequential Data Read/Write | 530/520MB/s |
| Access Time | <0.1ms |
| MTBF | >2,000,000 hours @25C |
| Flash Memory Management | |
| Flash Management Algorithm | Static and dynamic wear-leveling, bad block management algorithm |
| Supports Dynamic Power Management and SMART (Self-Monitoring, Analysis and Reporting Technology) | √ |
| Other Functions | |
| Support Power Failure Protection | √ |
| Support Secure Erase | Optional |
| AES Encryption, TCG OPAL2.0 | Optional |
| Thermal Adaptive Function | √ |
| Support TRIM | √ |
| Environment | |
| Temperature Ranges | Operation: -40°C to +85°C; Storage: -50 to 95°C |
| Humidity | 5-95% |
| Vibration | 10G; Peak, 10Hz~2000Hz |
| Shock | 1,500G, 0.5ms, half-sine wave |
Document
· Renice X10B mSATA SATAIII SSD Datasheet V1.0.pdf
